Mini Lancer final build

Описание: Mini Lancer final build
Important safety tips and don't mock my soldering
https://www.yourfinalvinyl.co.uk/coll...
Wingspan: 915mm / 36”
Length: 750mm / 39.1”
Weight: 780gr Approx without battery
Radio: 5 Channel
Motor/Battery: 1000Kv (3s), Battery upto 3100mah
ESC: 40A
Servos Required: 4 Servos MacGregor MG1703DS Recommended
The most important thing though is HAVE FUN
Wood stock & Hardware Supplied

M2 Clevises x 10
Threaded rod 8” x 3
Closed Loop kit (120cm Wire, Crimps x 4, Threaded adaptor x 2)
10SWG Saddle Clamps x 4
Magnets for hatch x 4
500mm Wing Seat Tape
80mm sticky back Velcro for esc and RX
M3 T nuts for wing fences x 4
Control Horns small x 5
Pinned Hinges x 16 (Assemble two halves together with a supplied pin pushed all the way through)
4 x M3 Nylon Bolts for the Wing fences
Screws for the undercarriage (3x7mm approx. x 8) & Control horns (2x13mm approx. x 8)
10SWG Collets & 4 Grommets (V.Small & Black!)
10SWG Elevator Joiner
Undercarriage Legs front and back
2 x Lite foam wheels
100cm Binding wire for the undercarriage joints
All Woodstock and laser cut parts required to finish the build
Required to complete build

T Nuts to suit your chosen motor
FLAT Building Board/Surface, Straight edge and Square
Wood plane for shaping the Leading edge
Sandpaper or Sanding tools to profile the fuselage and final sand all components
Pins
Z Bend pliers for the servo control rods (You can do a 90degree bend instead but you will need to source a suitable retainer)
Flux and solder for the undercarriage (Either use mini gas torch (preferred) or heavy duty soldering iron)
Wing Bands (Recommend 7”)
Covering of choice (Our prototype model was covered using Hendersons Chequer and bright orange film along with some transparent red Oracover)
Medium Cyano
Ultra Thin Cyano
Thick Slow Set Cyano
Activator (Optional)
PVA glue if you prefer over Cyano
5 minute Epoxy (Can use longer setting if that’s what you have)
