HOW TO DRAW DIAGONAL SCALE (QUE.NO.9) | UNIT : ENGINEERING SCALE

Описание: HOW TO DRAW DIAGONAL SCALE (QUE.NO.9) | UNIT : ENGINEERING SCALE

QUE : CONSTRUCT A DIAGONAL SCALE TO SHOW METER, DECIMETER AND CENTIMETER AND LONG ENOUGH TO MEASURE UPTO 6 METER. WHEN 1 METER IS REPRESENTED BY 2.5 CM. FIND THE R.F. AND INDICATE ON IT THE DISTANCE OF 4 METER, 5 DECIMETER AND 6 CENTIMETER.

FOR BETTER UNDERSTANDING, DRAW THE SOLUTION OF THIS QUESTION IN YOUR DRAWING BOOK.
