SNES Jr RGB + S-Video Mod and C11 Replacement (re-edit & re-upload)

Описание: Re-upload of Part 2 of my SNES Jr modding project, as the first few renders had audio clipping.

In this video, I do the Voultar SNES bypass amp install and re-enable s-video output on the SNES Jr. I also replace the C11 surface mount capacitor with a new 470 nF capacitor for the "ghosting" issue fix. Here's the link for my video doing the capacitor and voltage regulator replacements in Part 1:    • SNES Jr Capacitor and Voltage Regulator Re...



Table of Contents ##

0:00 -- Intro
0:12 -- Location of the work for the RGB bypass board
0:24 -- Dry-fitting the RGB bypass board
1:06 -- Clearing excess solder from multi-out pins
1:59 -- Second fitting of RGB bypass
2:44 -- Soldering RGB board to multi-out
5:52 -- Note about pins 9, 11, and 12 on the RGB board
6:18 -- Tinning the wire pads on the RGB board
7:18 -- Trimming and tinning ribbon cable for RGB and sync
11:00 -- Soldering RGB+S wires to the SNES main board (attempt 1)
11:35 -- Preparing ribbon cable for second RGB+S wiring attempt
14:11 -- Soldering RGB+S wires to the SNES main board (attempt 2)
19:10 -- Soldering RGB+S wires to the bypass board pads
22:28 -- Continuity testing the RGB+S lines & multi-out pins
26:04 -- Discussing s-video mod
27:27 -- Tinning up the chroma and luma pins on the S-RGB encoder
29:20 -- Soldering the luma & chroma wires to the S-RGB encoder
30:32 -- Routing s-video lines from S-RGB to RGB mod board
31:21 -- Soldering s-video wires Y/C pads on the Voultar board
36:13 -- Note about heat sink and cable routing during re-assembly
38:01 -- Continuity testing the s-video lines
38:52 -- Reassembly false start
39:35 -- PSA about how to not strip screw threads in plastic
41:46 -- C11 capacitor ghosting fix discussion
42:23 -- Removing C11
43:56 -- Prepping C11 pads
45:16 -- Soldering new C11 capacitor into place
47:07 -- How to test C11 in-circuit with multimeter
49:43 -- Triad power supply discussion
51:27 -- Using a 1Up Card console cleaner to clean cartridge connector
52:07 -- Testing s-video output
53:15 -- Testing RGB output
54:28 -- Final thoughts and shout-outs
