How to use L600-1 Pro drone ការប្រើតេឡេបញ្ជាដ្រូន L600-1 Pro with Screen remote control

Описание: Description:

Drone Model: L600 Pro Drone

Channel: 4 Channels

Gyro: 6 Axis

Motor: 1504 Brushless Motor

Pressure sensor: Height setting

Motor power: 25W

Electric power adjustment: 10A

Electric Adjustment Camera Angle: 90°

Camera Wide Angle: 120°

Remote Control Frequency: 2.4GHz

Laser obstacle avoidance: 360°

Laser obstacle avoidance distance: 20M

Remote Control Distance: About 1200 Meters (No Interference, No Occlusion)

Image Transmission Distance: 600-800 Meters (No Interference, No Occlusion)

Flight altitude:300M

Drone Battery: 7.4V/3000mAh Lithium Battery

Flight Time: Max 28 Minutes

Front Camera Photo Resolution: 3840*2160P

Front Camera Video Resolution: 1920*1080P

Bottom Camera Photo Resolution: 1280*720P

Bottom Camera Video Resolution: 1280*720P

Frame Rate: 25 fps

Photo Recording Mode: Remote Control + APP Control

Remote Control Battery: 3.7V/350mAh Lithium Battery (Included)

Quadcopter Size: 42*36*10CM (Unfoldable),16*8.5*10CM (Foldable)

Quadcopter Weight: 276.4g (battery in it)

Battery Weight: 81g

Obstacle Avoidance Device Weight: 24.2g

SD Card Support: do not support

Color: Silver Gray





Function Introduction:

1. 360° laser obstacle avoidance, automatically detect obstacles within 20 meters, making flight safer. (obstacle avoidance device optional)

2. GPS one click return to takeoff point, low battery return, no signal return

3. ① GPS intelligent tracking; ② Image following: Identify the shooting object and perform automatic following flight

4. Gesture recognition: Within 1-3m from the aircraft, make a photo gesture/camera gesture in front of the camera

5. Route multi-point planning flight: The aircraft flies independently according to the pre-set route, and players focus on shooting

6. Fixed point surround: Find the center point of the surround, and then use the joystick to move the desired surround radius

7. Aircraft retrieval function: continuously click on the GPS signal icon 3 times to open the map interface, where the map displays the final distance, longitude and latitude position of the aircraft

8. Pictures can be shared with music and videos: You can choose to share photos with one or more options, and videos can only be shared individually at a time

9. ESC 4K HD Wide Angle Camera, 90° adjusted by controller. (laser obstacle avoidance optional)

10. 7.4V/3000mAh plug-in intelligent lithium battery yields up to 28min flight time.

11. With foldable arm, small size, easy to carry.



Product List:

1 x L600 PRO Drone with or without obstacle avoidance device (optional)

1 x Barrier arrester (optional)

1 x Remote Controller

1 x USB Charging Cable

8 x Spare Propeller Blades

1 x User Manual

4 x Screws

1 x Screwdriver

1 x Backpack (optional)

1 x /2 x /3 x battery（including one battery in the drone) (optional)
