THE SET straight edge tool offers sophisticated design and unsurpassed accuracy.
This accessory sits perfectly sits atop the work surfaces of THE GRINDER 1, 2, and 3, enabling glass to easily slide between the grinding bit and the straight edge guide bar.
With THE SET, you can precisely grind rectangular and square-shaped glass to your desired dimensions, and finish your pieces with confidence and accuracy.
1. Turn off your GRINDER. Center THE SET horizontally across the lift grid, in-line with the grinding bit.
2. Place the positioning pins (on the underside) into the lift grid holes.
3. Loosen the adjustment knob counter clockwise and slide the adjustable plate to desired location.
4. Place glass flush against the aluminum bar. Slide the adjustable plate until the glass makes contact with grinding bit.
5. When adjustable plate is in desired location, tighten the adjustment knob by turning clockwise until it locks. Remove glass piece. Turn on your GRINDER.
6. Place glass flush against aluminum bar and grind by moving glass from right to left.
