Hi everyone! This is Top 3D Shop, and in this video, you will learn about the MetalFuse printing system by Chinese company Raise3D.

Based on indirect metal printing technology, the MetalFuse is a complete solution which includes the Forge1 metal filament 3D printer, the D200-E catalytic debinding machine which uses oxalic acid, and the S200-C vacuum sintering furnace. This combination makes it possible to obtain high-quality metal parts comparable to wrought iron in its mechanical properties.

The complete solution by Raise3D is recommended for cost-effective production of single metal parts as well as small to medium batch manufacturing. On top of that, the MetalFuse is energy efficient and more environmentally friendly compared to traditional SLM printing devices.

The catalytic debinding process used by the MetalFuse reduces binder removal time and allows increasing the final part density to 97% — when compared to a full-metal object made by traditional methods.

The Raise3D Forge1 is equipped with two extruders with the maximum hotend temperature of 300 degrees. Another benefit of the printer is its rather decent build volume — a cube with an edge length of 300 millimeters — as well as the layer thickness of one-tenth to 25 hundredths of a millimeter.

The Raise3D MetalFuse utilizes BASF metal filaments UltraFuse 316L and UltraFuse 17-4 PH as consumables; these composite filaments consist of 80-90% stainless steel of the corresponding grade and 10-20% resin binder. BASF plastics ensure excellent printing repeatability and high productivity.

In addition to the 3D printer, the MetalFuse system includes the D200-E cleaning station and the S200-C sintering furnace, which are used for post-processing of the so-called “Green parts”. The process is based on BASF's know-how in metal injection molding.

To prepare digital models for printing, Raise3D offers a special version of the ideaMaker software, namely the Metal Edition.

All the MetalFuse system devices, that is, the printer, cleaning station, and furnace, are equipped with large touchscreens featuring a carefully designed interface. Selecting the required profile and sending the job for printing or processing takes just a few clicks.

This is Top 3D Shop with the Raise3D MetalFuse printing system overview. Subscribe to our channel, leave your comments below, and hit the Like button if you’ve enjoyed the video. See you soon!
