Digital Electronics Lecture 15 | Implementation of Higher Order MUX Using Lower Order MUX
Автор: Saakshya Singh
Загружено: 2025-12-06
Просмотров: 84
Описание:
In this Digital Electronics Lecture 15, we will study how to implement higher-order multiplexers using lower-order multiplexers.
This lecture covers the complete design approach of creating large multiplexers like 8:1 MUX, 16:1 MUX, etc., using multiple 2:1, 4:1, and 8:1 multiplexers.
Topics Covered:
✔ Concept of MUX expansion
✔ Implementing 4:1 MUX using 2:1 MUX
✔ Implementing 8:1 MUX using 2:1 MUX
✔ Implementing 16:1 MUX using 2:1 MUX
✔ Important solved examples
✔ GATE, ESE, SSC JE & RRB JE exam-oriented theory
This lecture is very important for Electronics Engineering, Digital Logic, and Competitive Exam Preparation.
#digitalelectronics #multiplexer #muxdesign #higherordermux #logicdesign
#ece #electronicsengineering #gateexam #competitiveexams
#digitalcircuits #engineeringclasses
