STRING FOLDING || FZ-330-1 WITH COLLATOR MACHINE || 330 PPM || SACHET FOLDING || HIGH SPEED MACHINE
Автор: USHA MACHINE TOOLS
Загружено: 2024-09-30
Просмотров: 299
Описание:
Automatic Z Folding Machine is designed for folding of strings coming from FLOW-WRAP/ HFFS/VFFS Machines at a speed of upto 330 PPM. This machine consists of:-
1.) Inclined Conveyor :- The strings coming out of the FLOW-WRAP/HFFS/VFFS machines are taken onto this conveyor, The Sensor Mounted on this conveyor gives a signal of the presence of the string. This conveyor takes the string to the inlet of folding arm.
2.) Servo Controlled Folding Arm :- The Strings from the inclined conveyor are fed in the folding arm. The strings then travel forward with sandwich conveyors and the arm is positioned to perform the folding action. The two extreme ends of the the fold is set and the arm moves in a pendulum motion to perform the fold. The matrix's that can be achieved in this machine are, 2*2 up-to 5*5 depending on the thickness and stability of the product.
Folding Conveyor :- The Folding Arm places the strings on this conveyor where the desired matrix is formed.
3.) Roller Conveyor: The formed matrix is transferred onto this conveyor for collation. The rollers control the traffic on the collation end and are halted if need be.
4.) Servo Controlled Collation Unit :- The Folded strings are collated as per the customers requirement. A stack of strings can be formed with alternate stacking of sprouted products.
5.) Transfer Conveyor :- The stacked/collated strings are transferred for final packaging to the case packing unit.
Salient Features:-
High production (330 Pouches/Minute)
MOC S.S. 304/ M.S
PLC & Twin Servo Controlled System
Safety Enclosures with door switches.
Robust & Compact Design
For More Details feel free to contact us:
Website: www.fagu.co.in
Email: [email protected] / [email protected]
Tel. No.: +91- 8380096690
