💢Programming EtherNet/IP Protocol: C# With Allen-Bradley PLC Micro850
Автор: Industrial Networks
Загружено: 2025-04-19
Просмотров: 527
Описание:
What are the supported Ethernet protocols in Micro800?
Environment
Micro820
Micro850
Micro870
Those Micro800 series controllers that feature an Ethernet port can be connected to a local area network for various devices providing a 10 Mbps/100 Mbps transfer rate. The Micro820, Micro850, and Micro870 controllers support the following Ethernet protocols:
Ethernet/IP Client/Server (Class 3 Explicit messaging only)
Modbus TCP Client/Server
DHCP Client
Sockets Client/Server TCP/UDP
In addition, the Micro850 L50E and Micro870 L70E controllers with firmware version 21 or higher support EtherNet/IP Class 1 Implicit messaging, and the Micro870 L70E_24QBBN and L70E_24QWBN controllers support DNP3.
The controller can work with all protocols simultaneously, e.g. it can send two Ethernet/IP messages, three Modbus TCP messages, and one Socket TCP message all at the same time.
