The new Goblin RAW 700 size by SAB Heli Division

Описание: About Goblin Raw 700 size:
The SAB Goblin Raw features lightweight frame design, integrated canopy and simple structural solutions all designed around airflow. The open structure of the RAW provides a better sideway flying ability than any other model. The RAW shares many component concepts with the Kraken, even if there are slight differences. The simple open frame design makes the daily checkup easier, and the electrical components receive much better cooling due to the free airflow.

AIRFRAME weight: 2620gr (with blades, no battery, no electronics)
Main blade length: 650mm to 720mm
Tail blade length: 105 to 115 mm
Main rotor diameter: 1548 mm (with 690 mm blades included)
Tail rotor diameter: 284 mm (with 105 mm tail blades included)
Cyclic Servos: standard size 40mm
Tail Servo: standard size 40mm.
Main Rotor ratio: 11.8 to 8.8 (21T included: 10.1:1)
Tail Rotor ratio: 5.0-4.8:1 (26T included: 4.9:1)
Typical motor: 4525 series
Typical speed controller: 12S, 160-200 A

Battery size: 12S 4500-5500 mAh
