Demo model SITOP PSU6200 + SEL1200 - Overload
Автор: Siemens Knowledge Hub
Загружено: 2020-08-10
Просмотров: 703
Описание:
This is part 3 of the virtual demo model and contains the event of an overload. The demo model is a simulation of a real model and shows you the functionality of the SITOP PSU6200 all-round power supply and the SITOP SEL1200 selectivity module. To demonstrate the tripping behavior of the selectivity module, we simulate various faults in the 24 V circuit and compare it with the behavior of conventional miniature circuit breakers.
Further videos:
Part 1: Introduction • Demo model SITOP PSU6200 + SEL1200 - Intro...
Part 2: High inrush current and sequential switching on • Demo model SITOP PSU6200 + SEL1200 – High ...
Part 4: Short-Circuit • Demo model SITOP PSU6200 + SEL1200 – Short...
Part 5: Reset and manual shutdown of outputs • Demo model SITOP PSU6200 + SEL1200 – Reset...
