Titus restrictor clip (angle limiter) installation on T-type hinge
Автор: HGH Hardware
Загружено: 2021-10-22
Просмотров: 19839
Описание:
How to install the Titus angle limiter on T-type hinge
Open the door to about 70 degrees.
Using the attached break off tab, place the clip behind the hinge arm.
Open the door fully until you hear a snap.
Some key points:
• The curve on the restriction clip holder tab should match the curve of the hinge cup in order to be in the correct orientation.
• The edge of the door itself is what pushes the restrictor clip into place, so it must be done when mounted (not on loose hinges)—this action takes place when the hinge is opened fully and the door presses into the curve on the back of the hinge.
• Sometimes this action will snip off the tab, but if it does not, you can break it off manually.
• It is recommended to put a restriction clip on both hinges on the door for better angle limiting.
To purchase:
https://www.hghhardware.com/2349326/P...
(video courtesy of Robert Blatt)
