Steel Column Footing Foundation Detail
Автор: structuraldetails store
Загружено: 2015-09-05
Просмотров: 44757
Описание:
Steel Column Footing Foundation Detail
https://structuraldetails.com/product...
Typical detail for a footing foundation supporting a parallel wide flange (HEB/HEA or UC or I) steel column with a reinforced concrete pier column.
Typical wide flange steel column section ( HEB/HEA or UC or I ) welded on steel baseplate with full penetration butt weld with plate stiffeners. Anchor bolts detail and spacing, anchorage requirements, grouting, baseplate dimensioning, footing reinforcement, column pier reinforcement, stiffeners sizing, sub leveling concrete, water barrier layer.
For baseplate plan view size, bolt distances and dimensioning see :
– Baseplate Detail Steel HEB 240 Column Section (wide flange column) or
– Circular hollow section CHS Column Baseplate Detail ( CHS circular column )
