Cirrus Optimus Green CR:171B Handheld Sound Level Meter - Class 1
Автор: Vp ESS
Загружено: 2023-04-21
Просмотров: 304
Описание:
Specifically designed to accurately measure environmental noise and occupational noise with ease-of-use as its highest priority. The Cirrus Optimus Green handheld noise meter effectively assesses environmental noise impact over long and short periods of time, with an abundance of features available for operators. The essential piece of equipment for measuring and monitoring exposure to noise pollution and environmental noise sources.
All noise parameters are measured as one by the instrument, eliminating risks of selecting the incorrect settings and not measuring essential information. The Cirrus Optimus Green CR:171B has a comprehensive measurement capability. Equipped with a wide measurement range of 120dB whilst providing a complete picture of noise under investigation, as the overall Leq, LMax and statistical Ln% values are measured along with a range of noise profiles.
Results are presented on a high-resolution colour screen with a low light detector to illuminate the keyboard; the data is displayed in a clear and simple format along with real-time noise presented in a chart. Simultaneously, CR:171B measurements and data logger parameters are recorded and saved for later analysis.
Key Features
• IEC 61672-1:2013 Class 1
• Simultaneous measurement and data logging of all available parameters
• Frequency weightings: Simultaneous A, C & Z
• NR & NC values and curves on screen
• Tonal noise analysis
• Up to 28 statistical Ln % values
• Up to 30 seconds of audio notes with each measurement
• Acoustic Fingerprint™ audio triggering, recording and alerts during measurements for replay and analysis
• VoiceTag™ audio note recording and AuditStore™ measurement verification
• Repeating measurements with manual on automatic control
• Pause and back-erase functions
• High-resolution colour display and back-lit keypad for nighttime measurements
• 4GB memory capable of storing over 10,000 measurements (expandable up to 32GB)
• Compatible with CK:675 & CK:685 outdoor noise measurement kits
• Bluetooth® connectivity, compatible with Android and iOS devices
• Measurement control: Single or repeat measurement control with user selectable duration of manual, 1 min, 5 min, 10min, 15 min, 30 mins, 1 hour, Lden
• Connections:
o USB Type B to PC
o AC & DC output via ZL:174 (2 x Phono, 1m)
o Multi-pin IO for external power via ZL:171 cable (2.1mm socket)
o External power of 5v-15v via MultiIO socket via ZL:171 cable (2.1mm socket)
• Memory: 4GB
