Transform Your Register-Based Logic Routine to a UDFB

Описание: On this channel we’ve extolled the virtues of variable-based ladder logic programming with its User-Defined Function Blocks (UDFBs). In this hands-on session, we’ll start with an analog processing routine developed using register-based ladder logic and transform it into a variable-based UDFB. You’ll not want to miss this session where we demonstrate how to efficiently re-use and modularize existing register-based code.

To view the Cscape demo used in this video, click here: https://hornerautomation.com/wp-conte...

For more information on MQTT and other Horner products, please visit: https://hornerautomation.com/

For Cscape information, or to download a FREE copy, visit: https://hornerautomation.com/cscape-s...

For other Horner Live Q & A - Software/Firmware Events - check out our playlist -    • LIVE Q & A - Software/Firmware

Table of Contents
00:00 - Intro
01:13 - Agenda
01:46 - Logic Styles in Cscape
02:34 - Register vs Variable Based Logic
05:15 - User-Defined Function Blocks
07:07 - Transform Register Based Logic as UDFB
09:17 - Demo - Workflow to RB Logic to UDFB
09:57 - Isolate the RB Code to Core Function
12:50 -Add or Modify I/O Names
14:48 - Convert to a VB Program
15:46 - Strip Memory Mapping from your Variables
17:21 -Identify UDFB Variables & Create UDFB
28:34 - Test the UDFB
33:48 - Wrap-up
