MPC 60 Restoration: Power supply, Transformer and LCD Inverter tests
Автор: Scott Schiller
Загружено: 2026-01-20
Просмотров: 38
Описание:
In this video: inspecting the transformer and power supply on an AKAI MPC 60, as part of a larger restoration project. This MPC is a [J] version designed for the 100VAC power system in Japan, and so I use a North America-to-Japan step-down transformer in the process.
I also take a look at the LCD backlight inverter, and test the original inverter and backlight to see if they are still working.
Timestamps:
00:00 MPC60 demo, project overview
00:25 100VAC Japan step-down transformer
00:55 MPC60 power supply
01:08 PSU cable overview
02:46 Marking up cables and removal
06:08 PSU PCB underside
06:43 Capacitor tests
08:14 Safety first, live PSU test
10:19 Original LCD backlight and inverter tests
14:20 Coming up next, main PCB removal
