EPLAN ProPanel Terminal strips handling detailed parts
Автор: Roland Younk, EPLAN Quebec Canada Inc.
Загружено: 2021-03-09
Просмотров: 5014
Описание:
Uncommonly users may have assigned the parts of the terminals to the global terminal strip. It may work for the BOM, but for the placing of the terminal strip inside your 3D, it is not as nice. I prefer assigning the parts to each terminal as it should have been in the first place. See how I switch these around...
These videos are made by EPLAN Canada, they may not reflect your way of doing schematics in your country, be insured we can do what you would like to see with EPLAN. These videos intend to show how things can be done, but are not in anyway the only way you can do things with EPLAN. Always ask your EPLAN representative for more details. Check out your nearest location on our EPLANCanada.com web site.
