Learn to Track Down Shorts on Circuit Boards (Switch M92 Repair)
Автор: MobileSentrix Official
Загружено: 2025-10-08
Просмотров: 953
Описание:
In this video, I walk through the process of identifying a short circuit on a Nintendo Switch motherboard — a common failure point caused by a shorted M92T36 chip. But more importantly, this isn’t just about the Switch. The steps I show here apply to nearly any logic board, whether you're troubleshooting handheld consoles, tablets, or other devices.
You’ll see how to methodically check for shorts using voltage resistance measurements, visual inspection, and common-sense board layout logic. I show how to trace back from power rails to isolate the culprit and confirm the M92 chip as the faulty component.
If you’re learning board repair or just trying to get better at diagnosing dead devices, this video will give you a clear, repeatable workflow you can apply across the board. Let me know in the comments what you’d like to see diagnosed next.
#mobilesentrix #mobilerepair #nintendo
