Made: JLCPCB TinyDev TM1637 modular LED matrix clock with ATtiny85

Описание: This video is sponsored by JLCPCB. Go to https://jlcpcb.com to order your PCB's for only 2 USD plus shipment.

In this video I will show you how I made a small modular LED matrix clock for Arduino. It consists of the following parts:
a mini breadboard
the TinyDev development module, featuring an ATtiny85
the TM1637 6x5 LED matrix module
the 3x1 pushbutton extension module
the prototyped ISP-USB power module
a DS3231 realtime clock module

The video shows how I used EasyEDA to design my modules and how I used JLCPCB to manufacture the PCB's. I show you how I solder and test each module before assembling the clock. Next to that you can see my ATtiny44A development module and the modified TM1637 LED display (both shown in previous videos).

Video index:
0:00 - Introduction
0:30 - The prototype (using TM1637 display mod)
1:18 - Modules designed in EasyEDA (and made public)
3:37 - Ordering from JLCPCB
4:51 - Unboxing and inspecting the PCB's
7:32 - Soldering and testing the TinyDev module using ATtiny13A
9:02 - Soldering and testing the TinyDev module using ATtiny85
10:01 - Soldering the 3x1 TM16xx button extension module
10:20 - Reflow soldering the TM1637 LED matrix module
11:55 - Testing and fixing the TM1637 LED matrix module
12:40 - Putting modules onto the mini breadboard
12:55 - Prototyping the ISP-USB power module
13:18 - Last modifications and assembling
13:40 - Printing a box to house the clock
14:00 - Bye bye and don't forget to subscribe!

Links:
Arduino library for TM1637, TM1638 and more: http://github.com/maxint-rd/TM16xx
Arduino library for I2C on ATtiny with bugfix: https://github.com/maxint-rd/tiny-i2c
Shared designs on EasyEDA: https://easyeda.com/Maxint
More info about my PCB designs: https://github.com/maxint-rd/arduino-...
Arduino core used to program ATtiny85: https://github.com/SpenceKonde/ATTiny...
Arduino core used to program ATtiny13A: https://github.com/MCUdude/MicroCore
Video about modded TM1637 display:    • Mod: TM1637 LED matrix module
Video about ATtiny44A development module:    • Made: TM1640 LED matrix and ATtiny44 devel...

DISCLAIMER: The making of the modules and the used libraries is part of a private project that worked for me. If you decide to use this video to make your own modules or to use my libraries, you do so at your own risk. In no way I will accept any liability for any problems, damages of injuries you may encounter or cause. Unfortunately I have no means to provide support.
