EMAX F4 Magnum All in One FPV Stack for Quadcopters (Unboxing, Manual)

Описание: 6 in 1 Main Board:
F4 Flight Controller with OMNIBUSF4 Firmware (STM32F405 MCU and MPU6000 accelerometer/gyro connected via SPI)
Betaflight OSD (customizable flight info layout & FC parameters)
LC Filter (clean power)
5v/3A BEC (power for FC/OSD, VTX, RX, FPV Camera)
Blackbox (flight log recorder with 16mb flash memory)
Buzzer (for battery level warning or lost model finder)
3 UART pads
Addressable LED pad

VTX Board (Video transmitter):
48 Chanels (change via push button, chart in Manual)
Frequency band: 5362-5945MHz
Switchable Transmit Power (25mw/200mw)
Supply voltage: 4.5V-5.5V
Antenna port: 50Ω IPX U.FL connector

Antenna:
Dipole whip,
100mm,
Lightweight,
5.8ghz
80mm extension cable with SMA connecter for other antennas

Receiver:
Frsky XM+ (Micro RX)
16ch
Sbus
RSSI on Channel 15
Dedicated PPM/Sbus receiver input via RX pads

ESC:
Continuous current 30A and 40A burst x4 motor
Top quality MOSFETs running BLHeli_S firmware
Onboard current sensor: monitors mAh consumed, shows it on OSD to monitor battery level & peak power consumption
Protocol: DSHOT, Multishot, Oneshot 125.
Supply voltage 2-4S Lipo
Silabs EFM8BB21F16G 50mhz MCU

Other Accessories:
1 x B-017 XT60 female connector
1 x Hot-shrinkable tube Φ4.5*0.2*L20mm red
1 x Hot-shrinkable tube Φ4.5*0.2*L20mm black
1 x Silicon wire 14AWG L=80mm red
1 x Silicon wire 14AWG L=80mm black
1 x Plug with wire for LED_Strip
Standoff kit including nylon spacers, nylon screws, posts and nuts

-------------

https://www.ebay.com/itm/EMAX-F4-Magn...

*color of ESC and FC board is all black in V2, V1 was red + white + black (performance is unchanged)
