Vector Quality Renders from SolidWorks
Автор: Afshin Rahimi
Загружено: 2021-09-22
Просмотров: 3173
Описание:
This tutorial walks you through generating high-quality vector outputs from SolidWorks models which you can then use in reports, manuscripts, and presentations without worrying about losing quality over time or if the documents are zoomed in.
0:00 Connecting to the remote desktop (for UWindsor only)
0:20 Opening SolidWorks
0:50 Creating a drawing from the model in SolidWorks (for wireframe model)
2:20 Changing the styling of the drawing perspectives
3:47 Saving the drawing (as PDF)
4:50 Downloading and installing Inkscape (for vector graphics)
5:48 Opening Inkscape and loading the PDF file from the drawing
6:06 Editing the drawing in Inkscape in vector format
6:30 Saving the drawing from Inkscape as vector graphics (in SVG format)
6:41 Opening Microsoft Word to import the vector graphics and check the quality
7:30 Re-doing the process for a full render of the model
You can download Inkscape here https://inkscape.org/
