DIY Make Powerful CNC Machine at Home - Part 4: CNC Controller Wiring

Описание: In this video part see the following:
Y-Axis motors mounting
Cable chain installation along Y & X axises
Mechanical end stop/limit switches fixing on all axises
GX16 4-pin termination for all NEMA23 motors
GX16 2-pin termination for spindle wiring and other end lugs termination
GX12 2-pin termination for all end stop/limit switches and other end lugs termination

I used in this CNC controller box the following parts:
Arduino Nano running GRBL v1.1
TB6600 stepper motor drivers
PWM to Voltage 0:10 module
110V/800W Spindle power supply
24V/300W Power Supply
LM2596 Buck DC-DC step-down power module
Ferrules wire ends terminals
Electric cable terminal for 5 terminals (GND and VCC)

This machine based on linear motion combination between SFU1204 Ball screw and MGN12 Linear guides. I used also variety of aluminum extrusion profiles like 15180, 2080, 2040 and 2020. Additionally to 8mm thickness aluminum plates to fix them all.

Also don't miss the other parts
Watch Part 1:    • DIY Make Powerful CNC Machine at Home - Pa...
Watch Part 2:    • DIY Make Powerful CNC Machine at Home - Pa...
Watch Part 3:    • DIY Make Powerful CNC Machine at Home - Pa...

Excited to work on the next video to show you the planned additions:
Complete the controller wood box
Adding 92mm ventilation fan
Adding Emergency switch
Adding Probe
And more. Additionally, to test this machine very soon and share with you my experience
