Best satellite founder in Dish sitting with TV channel ! सैटेलाइट फाइंडर में ही देखो टीवी चैनल

Описание: Best satellite founder in Dish sitting with TV channel ! सैटेलाइट फाइंडर में ही देखो टीवी चैनल

General Features

DVB-S/DVB-S2 Constellation and Spectrum Analyzer supported

4.3 “inch definition TFT LCD screen

Measurement of BER, MER, C/N

CCTV camera Tester supported

13V/18V/22KHz/Lock/Power status display

DISEqC 1.0/1.1/1.2/USALS

Multi-media Payout supported

Multilingual OSD for worldwide use

USB2.0 interface available for software update

LED torch and stereo- loudspeaker inside

5000mAh long-life rechargeable Li-ion battery

Product Overview
Power Key: Press the power key for 3s to turn the unite on/off
LCD Screen: Shows menus and parameters clearly
Power light: Indicates the power status
Red: The unit is switched on or in charging

Red flashing: The unit has been short-circuited

Red/Green alternating flashing: The unit needs to be charged or it is fully charged

Lamp Light: switch on/off the utility LED on the back
22K Hz/ 13V/18V lights: Indicate the 22K Hz/ 13V/18V status
Function keys: F1-F4, to access functions indicated on the display
Arrow key and OK key: Press the arrow key to select the desired function then press OK to confirm
8. MENU key: Enter the main menu
EXIT key: Exit from the present menu back to the previous menu
10. SAT key: To start satellite search
FIND key: Enter the packet control menu, You can find the information about transponders quickly
TV/RADIO: To switch between TV and Radio services
RECALL: Show the previously viewed channel or list
III. Technical parameters

DVB-S/S2 Measurement

Modulation type

QPSK 8PSK 16APSK 32APSK

Symbol Rate

1Mbps-60Mbps

Frequency Range

950MHz-2150MHz

Input Signal Level

-65dBm-25dBm

Input Impedance

75 ohm

Code Rate

1/4 , 1/3 ,2/5 ,1/2 ,3/5 , 4/5 ,5/6 ,8/9 , 9/10

LNB Switch Control

22KHz DisEqC 1.0/1.1/1.2

DiSEqC

1.0/1.1/1.2/1.3(USALS)

Full HD Digital Satellite dB Meter
Brand: Solid
UPC: 890430830128
Model No.: SF-828HEVC
Availability: In Stock
MRP: ₹8,000.00
Special Price: ₹5,850.00
Contact us, if you want to Buy more Qty.

Offline Retailers: Qty-wise discounted prices are applicable for dealer accounts only. Contact us to convert your account.
Online Sellers: Special Pricing for dropship accounts.
