Toyota Air Jat Looms I Working Performance I JAT 710 |

Описание: #toyotaairjetloom #jat710 #jat710working #textile
Automatic TOYOTA JAT 710 Airjet Loom
Automatic Grade I Automatic
Brand I TOYOTA
Loom Dimension I 190
Machine Speed I 900(RPM)
Machine Type I Automatic
Minimum Order Quantity I 4 Piece


Product Description
Toyota JAT 710, Model: JA2S-190TP-EF-T710Yom: 2005 x 34 Loom'sYom: 2012 x 2 Loom’sww: 190 cmsColors: 2 Colors
Equipped with:Staubli 1661 CAM (6 Installed)
Accessories:2 Feeders, 1.5 Beam 1000mm, 1 Batching Motion, 6 Frames
RPM: 950Very well maintained.Currently Stopped On Mill Floor, Empty Running Possible.

A)
30 Sets Toyota Jat 710 Air Jet Looms With E-Shedding
Type : JA6S-190TE-EF-T710
Yoc 2006 X 16
Yoc 2008 X 14 UV
Reed Space : 190 Cm
Shedding Motion 16 Shaft + 16 Heald Frames
6 Electric Drum Feeder
Single Beam 17 Machines & Double Beam 13 Machines
Electric Source : 380 V 50hz

B)
40 Sets Toyota Jat 710 Air Jet Looms With Cam Motion
Type : JA4S-190TP-EF-T710 - Yoc 2003
Reed Space : 190 Cm
Shedding Motion Positive Cam Motion (Staubli 1651) 6 Shaft+4-Heald Frames
4 Electric Drum Feeder
Electric Source : 380 V 50hz
Accessories Per Loom For A) And B)
1 Speed Control Inverter
1.5 Warp Beams (Dia. 800 Mm)
1.0 Cloth Rollers
1 Reed
7000 Droppers
7000 Heald Wires (J-Type 331 Mm.)

C)
14 Sets Toyota Jat 710 Air Jet Looms With Cam Motion
Type : JA2S-340TP-ET-T710 - Yoc 2003
Reed Space : 340 Cm
Shedding Motion By Positive Cam Motion (Staubli 1651) + 6 Heald Frames
2 Electric Drum Feeder
Electric Source : 380 V 50hz


Accessories Per Loom
1 Group Inverter (Overall)
1.5 Warp Beams (Dia. 800 Mm)
1.0 Cloth Rollers
1 Reed
7000 Droppers
7000 Heald Wires (J-Type 280 Mm.)
Tuck In Selvedge System
Mechanic Full Leno Selvedge System
