フラップター：Flaptter19-8 of Castle in the sky Flight with New wing

Описание: フラップター：Flaptter19-8 Flight with New wing
Flaptter 19-7 of LAPUTA (Hayao Miyazaki 's animation)　
With new wings 新しい翼
I decreased the flapping amplitude of rear wings.　安定性を高めるため後ろの翼の羽ばたきの振幅を減少させた。
I changed flapping cycle of wings.
A flap cycle of front wings is delayed by 90 degrees in a flap cycle of rear wings.　前の翼の羽ばたきサイクルは後ろの翼の羽ばたきサイクルに90度遅れる。
Very Good Flight. 安定した飛行です。
Good Flight. 操縦性も良くなり良好な飛行です。
Flaptter 19-8
Width 80cm
Length 24cm
Weight 254g (Young Dola 6g)
battery Lipo 3cell 450mAh45g
Total flight weight 254g
Receiver:Corona 4Ch Single Conv. Rx 72MHz
cryistal: Castle Creations Micro Crystal Berg (72MHz)
Servo: Rear wing (DM 4.7g servo *2)
Motor: AXI2203　race
Gear:Main Gear 0.4M66T Acetal *2 (shaft3mm, 3mm ball bearing)
Spur Gear M0.4 55T, 64P8TPinionWire(4mm ball bearing)
Pinion Gear M0.4 16T
ESC:H-KING 12A Fixed Wing Brushless ESC
Battery: Lipo　3cell 450mAh G3
Control: 3CH (a motor, rear wing 2 servo)
Film of a wing: Orcon film
For more details 詳細は　
http://homepage2.nifty.com/smark/Haba...
