155635 MITSUBISHI LARGE CAPACITY CNC RAM TYPE EDM

Описание: MITSUBISHI LARGE CAPACITY CNC RAM TYPE EDM

** WITH AUTOMATIC TOOL CHANGER USING SYSTEM 3R TOOLING **

MODEL: EX22 S/N: 58E22199 NEW: 1999

TRAVELS:
X AXIS ................................. 19.7"
Y AXIS ................................. 15.8"
Z AXIS ................................. 13.8" TRAVELS
WORKTANK INNER DIMENSINS ............... 37.45" x 25.6" x 15.8"
MAX. WORKPIECE WEIGHT .................. 2,200 LBS.
DISTANCE BETWEEN TABLE SURFACE AND
ELECTRODE INSTALLATION SURFACE ....... 10" TO 24"
MAX. ELECTRODE WEIGHT .................. 220 LBS.

MINIMUM COMMAND UNIT ................... 0.00004"

DIELECTRIC FLUID RES. .................. 570 LITERS
FILTERING PRECISION .................... 5 MICRONS

APPROX. DIM. INCL. TANK ................ 55" x 78" x 95"H
APPROX. MACHINE WEIGHT ................. 7,700 LBS.


MACHINE FEATURES:
FP60E POWER SUPPLY & "C11" CONTROLLER UNIT
32 BIT
FUZZY LOGIC
14" COLOR CRT DISPLAY
RS232C INTERFACE & 3.5" FLOPPY DISC DRIVE
CHILLER
AUTOMATIC FIRE EXTINGUISHER
MANUALS & DISCS

OPTIONS:
AUTOMATIC TOOL CHANGER USING "SYSTEM 3R" "COMBI" TOOLING.
UNIT HAS 32 POSITIONS FOR "JUNIOR" TOOLS, 16 POSITIONS
FOR "MACRO" TOOLS.


** PROFESSIONALLY DE-INSTALLED BY MITSUBISHI ON 09/14/2016 **
** SUPERB CONDITION & APPEARANCE **
** INSPECT UNDER POWER IN OUR HARRISON, NJ WAREHOUSE **
