Making a LED Matrix with 3D Effect

Описание: This video shows how I built the LED Matrix with 3D Effect. The grid of the LED Matrix consists of 192 rhombuses. Each rhombus is light up with one LED. WS2815 LED Strips are used. The diffusor is a Polypropylene foil. The front cover foil is made with a cutting plotter.

00:00 intro
00:13 grid drawing
00:20 base plate
01:07 cut LED strips
01:55 glue LED strips
03:18 solder 1x strips
03:55 solder data cables
04:57 grid mounting positions
05:30 solder power cables
05:59 PVC rods for grid
06:59 cut grid
07:20 glue grid
09:06 aluminum frame
10:15 solder power injection cables
11:26 schematic & mount controller
12:22 first test & issues
12:41 paint grid
12:54 apply foam tape
13:34 front foil
16:12 front cover
18:53 assemble LED Matrix
19:59 mount LED Matrix
20:21 finished LED Matrix

Key features:

192x WS2815 LEDs (30LEDs/m strips)
base material: 3mm white acrylic glass
front cover material: 3mm transparent acrylic glass
diffusor foil 0.5mm Polypropylene
T-slot aluminum profiles on back
controller Wemos D1 Mini Pro with ESPixelStick Firmware 4.0
level shifter 74HCT125 to convert 3.3V logic up to 5V
animations made with xLights
SD card slot to save and play back animations

::::::::::::::::::::

new version with 3D printed grid
   • 3D Printed LED Matrix with 3D Effect

ESPixelStick Controller Firmware
https://github.com/forkineye/ESPixelS...

xLights
https://xlights.org/releases/

xLights model
https://www.dropbox.com/sh/9237yxxcti...

Drawing grid
https://www.dropbox.com/sh/5ena86gqur...

::::::::::::::::::::
