Q3.2 - A hexagonal pyramid base 30 mm side and axis 65 mm long...😃 - SECTIONAL PLANE PROBLEM
Автор: CYBER ARCHIS OP
Загружено: 2026-01-01
Просмотров: 46
Описание:
Follow Engineering Drawing Playlist: • Engineering Drawing [FULL COURSE]🔥
A hexagonal pyramid base 30 mm side and axis 65 mm long is resting on its base on the HP, with two edges of the base parallel to the VP. It is cut by a section plane perpendicular to VP and inclined at 45° to the HP, intersecting the axis at a point 25 mm above the base. Draw the front view, sectional top view, sectional side view and true shape of the section.
UEM Kolkata, IEM Kolkata, IEM Newtown, IEM Saltlake, UEM Jaipur, Engineering Drawing, First year
Engineering Drawing question explained in english easily. This can be understood by anyone.
