hills reliance r128 programming entry and exit and basic programming / zone programming (NX panel)
Автор: 8tek
Загружено: 2024-08-28
Просмотров: 1643
Описание:
An introduction to programming this NX Hills r128 panel type
how to get into programming and how to exit as well as modifying zones
Hills Reliance Specifications
Operating Power 16.5 VAC 25, 40, or 50 VA Transformer
Current Draw 60 mA Standby
150 mA Alarm
Auxiliary Power
w/ 25 VA Transformer 12 VDC 0.5A Regulated
w/ 40-50 VA Transformer 12 VDC 1.0A Regulated
w/ NX-320E 12 VDC 2.0A Regulated
Loop Resistance
Standard Loop 300 Ohms max.
2-Wire Smokes 30 Ohms max.
Built in Siren Driver 3 tone (Steady, Yelp, Evacuation)
Operating Temperature 0 to 49˚C
4-Wire Smokes 300 Ohms max.
Loop Response 500ms
R12/128 Backup Battery 12 V 7 Ah Sealed-Lead Acid
R8 Backup Battery 12 V 4 Ah Sealed-Lead Acid
R12/128 Dimensions 289 mm W x 291mm H x 93mm D
R8 Dimensions 236 mm W x 212mm H x 91mm D
R12/128 Shipping Weight 4 kg
R8 Shipping Weight 2 kg
R128 DAS Order Code S4133
R12 DAS Order Code S4142
R8 DAS Order Code S4697
