MSI 865PE Neo2 MS-6728 DDR Socket 478 AGP 8x i865PE Mainboard ATX

Описание: ATX μητρική για ρετρό επιτραπέζιους υπολογιστές MSI 865PE Neo2 MS-6728 v.1 με Socket 478 θύρα AGP 8x τσιπάκι intel i865PE και μνήμη ραμ τύπου DDR.
ATX motherboard for retro desktop computers MSI 865PE Neo2 MS-6728 v.1 with Socket 478 AGP port 8x intel i865PE chip and DDR RAM memory.

Υποστηρίξτε μας κάνοντας εγγραφή στο κανάλι μας εδώ:    / @oldtechpcs   και μη ξεχάσετε το καμπανάκι για να βλέπετε κάθε νέο μας βίντεο. Σας ευχαριστούμε πολύ που είστε εδώ μαζί μας σε αυτό το τεχνολογικό ταξίδι.

ΑΚΟΛΟΥΘΗΣΤΕ ΜΑΣ ΑΚΟΜΗ
PINTEREST εδώ:   / _boards
FACEBOOK εδώ:   / 61574430897465

Support us by subscribing to our channel here:    / @oldtechpcs   and don't forget to click the bell to see our new videos. Thank you so much for being here with us on this technological journey.

FOLLOW US ALSO
PINTEREST here:   / _boards
FACEBOOK here:   / 61574430897465

Πληροφορίες:
Η MSI 865PE Neo2 MS-6728 ήταν μια μητρική πλακέτα τύπου ATX βασισμένη στο chipset της Intel 865PE, σχεδιασμένο για επεξεργαστές Socket 478 όπως ο Intel Pentium 4. Ήταν γνωστή για τις δυνατότητες δυναμικού overclocking καθώς και για τις λειτουργίες Gigabit LAN, ICH5 RAID και ελεγκτή Promise RAID.

Imformations:
The MSI 865PE Neo2 MS-6728 was an ATX motherboard based on the Intel 865PE chipset, designed for Socket 478 processors such as the Intel Pentium 4. It was known for its dynamic overclocking capabilities as well as Gigabit LAN, ICH5 RAID, and Promise RAID controller features.

DOWNLOAD Manual PDF for MSI 865PE Neo2 MS-6728 V.1.0 here: https://mega.nz/file/kn5QVTRZ#Ub2DTlw...

Specifications:
CPU
Socket 478 for Intel Pentium 4 (Northwood/Prescott)
processor up 3.2GHz/FSB 800 FSB 400/533/800 MHz
Chipset
Intel Springdale 865PE Chipset
FSB 400 (Northwood only)/533/800 MHz
Single or Dual channel DDR 400/333/266 non-ECC memory up to 4GB
AGP 8x or 4x at 0.8V (AGP 3.0) or 4x at 1.5V (does not support 3.3V or 5.0V)
Intel ICH5 Chipset
Integrated Hi-Speed USB 2.0 controller, 480Mb/sec, 8 ports
2 Serial ATA/ 150 ports
2 channel Ultra ATA 100 bus Master IDE controller
PCI Master v 2.3, I/O APIC
Supports both ACPI and legacy APM power management - Serial ATA/150
On-Board IDE
Dual Ultra DMA 66/ 100 IDE controllers integrated in ICH5
Supports PIO, Bus Master operation modes
Can connect up to 4 Ultra ATA drives
Serial ATA/ 150 controller integrated in ICH5
Up to 150MB/s transfer speed
Can connect up to 2 Serial ATA drives
Audio
6 Channels software audio codec C-Media 9739A
Compliance with AC97 v2.2 Spec
Meet PC2001 audio performance requirement
Support SPDIF out via S-Bracket only
LAN
Intel 82562EZ
Integrated Fast Ethernet MAC and PHY in one chip
Supports 10Mb/s, 100Mb/s
Compliance with PCI 2.2
Supports ACPI Power Management
Dimension
30.5 cm(L) x 24.4 cm(W) ATX Form Factor
