How to Retrofit a 2006-2012.5 Hot Spot and Solana Spa with the 76840 Hawk Control Box

Описание: In this video, we show you how to retrofit a 2006 - 2012.5 Hot Spot and Solana spa with the 76840 Hawk control box and the 76843 topside control panel. Please visit us at backyardplus.com for all your OEM Hot Spring, Tiger River, Limelight, Hot Spot and Solana replacement parts. Use our parts finder serial database to help identify parts that belong to your specific hot tub make, model and year: https://backyardplus.com/parts-finder/ For the best prices and service on all your Hot Spring replacement parts, check out: https://backyardplus.com/
To purchase the 76840 Hawk control box, check out: https://backyardplus.com/parts/76840-...
To purchase the 76843 control panel, check out: https://backyardplus.com/parts/76843-...

00:00 Beginning
00:20 Tools you will need
00:32 Disconnect power, drain the spa
00:42 Remove the doors
00:52 Loosen the nut on the heater mounting stud
01:06 Disconnect the incoming power, jet pump, ozone and heater
02:15 Disconnect the Limit therm, pressure switch, Reg therm spa light and control head.
02:30 Loosen the compression fittings and remove the heater
02:50 Remove the old box
02:59 Install the new box
03:10 Insert the heater mounting stud and install the heater
03:54 Connect the bonding wire, sensors pressure switch & light
04:40 Connect the heater wires to heater black and heater white
04:50 Remove the power cord strain relief clamp
05:12 Connect the incoming power wires
05:34 Install the power jumper
05:50 Connect the heater ground
06:02 Connect the jet pump wires
06:50 Connect the ozone
07:13 Strain relief clamp and connect the heater bonding wire
07:35 Break the seal and remove the control panel
07:55 Remove all silicone, dirt and debris from the bartop
08:20 Plug the control panel into the J9 control head interface
08:34 Place a silicone bead on the control panel
08:57 Press the new control panel down firmly and clean up excess
