CR-30 Linear X Rail Upgrade
Автор: GridSpace
Загружено: 2021-06-05
Просмотров: 5573
Описание:
This video demonstrates a simple mechanical upgrade for the CR-30 3DPrintMill that substantially increases the rigidity of the X axis and greatly reduces print defects due to torsional rotation or deflection of the hot end.
This and future mods will be covered in this forum thread: https://forum.grid.space/t/another-ro...
Drill hole template
https://cad.onshape.com/documents/cb3...
X linear rail aligner
https://cad.onshape.com/documents/cb3...
00:00 Description
00:52 Clear X Plate
01:06 Loosen Steppers
01:20 Unclip Belts
01:35 Drill X Plate
01:50 Prepare Linear Rail
02:07 Rail Placement
02:18 Rebuild Plate
02:54 Attach Belts
03:20 Tension Belts
03:33 Adjust Y and Level
