Setup the Modbus TCP communication between a Festo CMMT drive and a Rockwell Micro 850 PLC
Автор: Festo North America
Загружено: 2023-08-03
Просмотров: 3111
Описание:
This video will help you setup the Modbus TCP communication between a Festo CMMT drive and a Rockwell Micro 850 PLC. To access the relevant files, simply head to the Festo website and navigate to the "Expert Knowledge" section. There, you can find the files you need by using the search term "CMMT Modbus."
https://www.festo.com/us/en/search/?t...
0:25 Hardware description
1:57 Software description
2:35 Setup in Festo Automation Suite
3:35 Setup in Rockwell Connected Components Workbench (CCW)
5:25 Importing the Function Block into the project
7:17 Adding Modbus TCP READ block to the program
10:13 Configuring Global Variables for READ
16:05 Copying data from CMMT drive
17:63 Adding the CMMT Function Block
19:31 Adding Modbus TCP WRITE block to the program
20:10 Copying data to CMMT drive
22:43 Configuring Global Variables for WRITE
25:45 Mapping the I/O for the CMMT Function Block
31:55 Getting online with the PLC
37:05 Testing the CMMT Function Block
