The steel-concrete composite steel deck bridge

Описание: The steel-concrete concrete composite bridges started to be designed in the 30s of the last century.They are formed with a concrete deck and steel beam ,which can be I-section or a box girder,Despite the configuration, the final solution strongly depends on the engineer experience duo to the great number of design variables,
steel box and I-girder bridges have been used in the construction of highway bridges for many years. Box sections have excellent bending and torsional rigidity compared to steel I-girder, and the box section provides an esthetically pleasing structure, but the amount of steel required can sometimes exceed that for standard I cross section.
