Module 2 of 3 - Importing, Visualizing and Cleaning Up Data, Survey Terrain Model

Описание: Date: 10/28/15
Presenter: John Hazlip, Survey & Mapping

The second of a three part series on Bentley’s Open Roads Technology for location surveying. Content will focus on importing processed data, cleaning up the database, and building/editing Terrain Models from survey data.

FDOTSS4 Design Survey Workflow document:
http://www.fdot.gov/cadd/downloads/do...

Presentation:
http://www.dot.state.fl.us/ecso/downl...

Question & Answers:
http://www.dot.state.fl.us/ecso/downl...

Walkthrough:
http://www.dot.state.fl.us/ecso/downl...

Table of Contents:

00:00 - Introduction
01:05 - Importing Data into Bentley Survey
01:12 - Importing a CAiCE PT4 File
01:41 - Importing an XYZ and OBS Files
01:55 - Importing a CTL File
02:01 - Importing XML, SRV, KCP and More Files
02:20 - Importing PT4 File (Live)
04:10 - Importing an XYZ and OBS Files (Live)
04:23 - Annotation Scale Lock OFF for Importing
05:50 - Survey Data Tree to Display Importing
06:33 - Importing a CTL File (Live)
08:14 - Adjustment Category
10:21 - Visualizing - Project Explorer
10:41 - Visualizing - Survey Data
11:35 - Visualizing - Civil Standards - Survey Display
12:09 - Visualizing - Level Display
13:01 - Visualizing - Survey Filters
14:29 - Cleanup Survey Data
14:54 - Cleanup Using Element Information Box
16:41 - Visualize Civil Standards
18:53 - Custom Survey Filters
23:05 - Cleanup Using Survey Database
23:47 - Using Task Menu - Civil Tools
25:03 - Using Project Explorer - Linear Features
25:47 - GEOPAK GPK File
27:19 - Cleanup with Chain Editing
32:11 - Terrain Models from Survey Data
32:37 - Survey Database Cleanup
34:00 - Point Feature Cleanup
34:44 - Linear Feature Cleanup
36:25 - Create Terrain Model
38:32 - Resolving Crossing Chains
39:59 - Move a Point Along Linear Feature
40:26 - Change Points within Manage Point List
43:20 - Changing Features
48:09 - Apply a Feature Definition
48:36 - Export Terrain Model
49:52 - Avoiding Pitfalls
50:36 - Question: Could Concrete Slab be Edited by Adding a Second Comma?
