Landing a Microwave or RF Probe in a Cryogenic Probe Station, Ensuring Optimal Contact

Описание: In this video from Lake Shore Cryotronics, we demonstrate the steps to land and planarize a microwave or RF GSG probe on a sample landing pad in a probe station. Although the steps shown involve probes sold by Lake Shore, many of the steps generally apply to most commercially available probing platforms (for specific directions on the use of a non Lake Shore probe or probe station, please consult the manufacturer).

NOTE: Before attempting to land a microwave/RF probe for the first time, we recommend that you first get familiar with the probe landing probe process while using a less-expensive DC probe, as shown in Lake Shore’s “Landing a DC Probe” video.

About Lake Shore Cryotronics
Supporting advanced research since 1968, Lake Shore (http://www.lakeshore.com) is a leading innovator in measurement and control solutions for materials characterization under extreme temperature and magnetic field conditions. High-performance product solutions from Lake Shore include cryogenic temperature sensors and instrumentation, magnetic test and measurement systems, probe stations, and precision materials characterizations systems that explore the electronic and magnetic properties of next-generation materials.

Lake Shore probe stations are micro-manipulated platforms used for non-destructive testing of materials and devices on full and partial wafers, whether for measuring magneto-transport, electrical, electro-optical, parametric, high Z, DC, RF, or microwave properties. They are specially engineered for testing as a function of temperature and magnetic field. To see Lake Shore’s selection of probe stations, visit: http://www.lakeshore.com/products/Cry...
