3.5mm Z Purlin Quick-change Roll Forming Machine, 100-300mm Size, Z Shaped Solar Channel Machine

Описание: At MTC Machinery, we continue to innovate in roll forming technology to help our customers meet growing demands for strength, flexibility, and efficiency in steel construction. Our latest Z purlin roll forming machine is designed to deliver unmatched precision and productivity. It supports a material thickness of up to 3.5mm and offers fully automatic width adjustment from 80mm to 300mm, eliminating manual setup and maximizing output speed.

This video presents a trial running overview of this powerful roll forming line and dives into the core features, advantages, and practical applications that make it a top choice for structural steel manufacturers worldwide.

Overview of Z Purlins
Z purlins are structural members commonly used in steel buildings, warehouses, pre-engineered buildings (PEBs), and solar panel mounting systems. Their Z-shape offers superior strength and load-bearing capacity, making them ideal for roof and wall support. Additionally, Z purlins can overlap at joints, enabling long-span installations with less steel usage.

Modern building projects often require Z purlins in various sizes and thicknesses. This machine was engineered specifically to meet those requirements with efficiency and precision.

Key Features and Specifications
This roll forming machine includes advanced mechanical and electronic systems to ensure stable, high-speed operation with minimal downtime. Some of its core technical specifications include:

Material thickness: 1.5–3.5 mm
Material type: Galvanized steel, cold-rolled steel, black steel
Adjustable width range: 80–300 mm (automatic adjustment via servo motors)
Production speed: 15–18 meters/min
Roller stations: 18 stations
Main Power: 22KW
Drive system: Chain-sprokets driven
Cutting system: Hydraulic post-cutting
Control system: Industrial Computer
Optional: automatic stacker, auto decoiler

Fully Automatic Size Adjustment
One of the most outstanding features of this Z purlin machine is its automatic size adjustment function. Using servo motors and digital positioning, the machine can shift forming rolls and guides precisely to match the selected width. This significantly reduces changeover time—down to under 3 minutes—and ensures high-accuracy output without manual error.

Operators simply input the desired size through the HMI touch panel, and the machine will self-adjust all relevant stations automatically, improving overall productivity.

Workflow and Trial Run
During trial running, the machine was tested with 3.5mm galvanized steel, producing clean, high-quality Z purlins with no surface defects and accurate dimensions. The workflow is as follows:
Decoiler feeds the steel coil
Leveler flattens the strip
Servo feeder and optional punching system apply holes
Roll forming unit gradually forms Z shape
Hydraulic cutting system cuts to length
Finished purlins are collected or stacked

All systems were controlled via the integrated PLC, and operators were able to switch between sizes quickly with no manual adjustments.

Application and Benefits
This Z purlin roll forming machine is suitable for a wide range of structural projects:
Steel warehouses and workshops
Solar panel mounting structures
Pre-engineered buildings (PEB)
Agricultural buildings and storage sheds
Logistics centers and commercial steel framing

Key benefits include:

Reduced setup time and labor cost
Consistent high-speed production
Flexibility to produce multiple sizes
Low maintenance and long service life
Superior product accuracy and strength

Global Usage and Support
MTC’s Z purlin machines have been successfully delivered to customers in more than 40 countries, including Saudi Arabia, India, Chile, Turkey, and South Africa. Clients praise the machine’s durability, easy interface, and responsive after-sales service.

If your business needs a robust, flexible, and highly automated solution for Z purlin production, this machine is the ideal investment.

📞 Contact our sales team today to schedule a free consultation, get a detailed quotation.
📧 Email: [email protected]
🌐 Website: https://mtc-china.com
C & Z Purlin Quick Change Roll Forming Machine: https://mtc-china.com/roll-forming-ma...

Take your steel framing production to the next level — with MTC Machinery.
