Tilt and Slide Easy Access

Описание: Schüco Tilt-Slide Easy Access Door Operation
The Schüco tilt-slide (PASK) easy access door combines the benefits of sliding and tilt-turn functions, offering a versatile and user-friendly operation.
Opening Sequence:
Tilt Position:
Turn the handle 90° to bring the sliding vent into the tilt position.
This allows for ventilation while maintaining security.
Slide Position:
From the tilt position, continue pressing down on the handle.
The handle will spring back, and you can then push the sliding vent open at the bottom.
Closing Sequence:
From Slide Position:
Slide the vent until it automatically moves into the bottom locking point (tilt position).
Turn the handle upwards to fully close the unit.
From Tilt Position:
Simply close the vent and turn the handle downwards 90° into the closed position.
Key Features:
The door units "float" on ball-bearing rollers, making them extremely easy to open and close.
The system can bear vent weights of up to 180 kg and allows for basic depths of up to 90 mm with an opening width of 110 mm.
An optional soft closing mechanism increases ease of operation and reduces the risk of incorrect operation1.
The Schüco tilt-slide easy access door offers a combination of functionality and convenience, making it suitable for large window door openings while providing excellent thermal insulation and weathertightness.
