7-SEGMENT LED DISPLAY MAX7219 & SHIFT REGISTERS - Arduino tutorial #21

Описание: In this Arduino tutorial for beginners I'll teach you how to control a MAX7219 8-Digit LED Display and how shift registers work.

The Arduino for beginners tutorials series guides you through the world of Arduino. A video is around 10 minutes and shows you step-by-step how to build the circuit and write the code. The website contains the course material, circuit diagram, Arduino code and shopping list of all the components used in the tutorial.

⬇️ Arduino code, circuit diagram and part list https://arduino-tutorials.net/tutoria...

👉 More tutorials and projects on https://arduino-tutorials.net

🇳🇱 Deze tutorial is ook in het Nederlands beschikbaar    • 🇳🇱 MAX7219 8-DIGIT LED DISPLAY & SCHUIFREG...

CHAPTERS
00:00 Introduction
00:08 Components
00:36 MAX7219 8-Digit LED Display
00:52 Shift registers
03:23 Building the circuit
04:06 Arduino code (simple)
09:43 Custom characters
11:41 Arduino code (counter)
21:06 Arduino code (characters)
