Robot Calibration - RoboDK

Описание: This video shows how to calibrate an industrial robot with RoboDK using a laser tracker. The calibration is done in less than 15 minutes (20 minutes if we add 60 validation measurements). In this example, the accuracy of a KUKA KR 6 R700 is improved by a factor of 10. A stereo camera can also be used to calibrate robots.

The calibration procedure is divided in four steps:
00:00 – Introduction
00:21 – Overview of the Four Calibration Steps
00:52 – Reference Measurements
01:38 – Step 1: Base Frame Calibration
03:39 – Step 2: End Effector Calibration
05:31 – Step 3: Calibration Measurements
13:21 – Step 4: Accuracy Validation
20:22 – Final Results

This video is part of the RoboDK Documentation. You can learn more in the RoboDK Documentation here:
https://robodk.com/doc/en/Robot-Calib...
