OpenWRT - Install and Configure LTE modem in QMI mode - Quectel EC25 & Wallys DR4029

Описание: In this video, we are going to install the LTE/4G module on OpenWRT router and configure the modem to work in QMI mode. I am using the Quectel EC25-E LTE module and Wallys DR4029 router board. The router has a mini PCIe connector for LTE module but it is actually a USB 2.0. Because of this, the guide will also work with 3G/ LTE USB modem. At the same time, this guide can be applied for 3G (HSPA), 4G (LTE) and 5G module.
The steps is very easy: You just need to install the requires drivers and uqmi. When the modem is detected as cdc-wdm, go to Luci and create an interface, fill in the APN information and assign it to WAN firewall zone and you should be good to go.

Video timeframe:
00:00 - Introduction about LTE module on OpenWRT
00:19 - Hardware preparation - LTE module, Router, Antenna, SIM card
02:08 - Protocols used for data connection on OpenWRT
02:40 - Install requires packages for QMI protocol
04:00 - Verify if the modem is properly detected
04:50 - Communicate with the modem and basic AT commands
06:30 - Create the LTE WWAN interface with Luci & APN set up
08:22 - Ping and Speedtest
09:26 - How to query modem manufacture and model?
10:34 - How to exit minicom
10:58 - Another speedtest and CPU usage with MY Hotlink

You can find the detail review of the DR4029 here    • OpenWRT - Wallys DR4029 Router Board - SFP...
OpenWRT QMI protocol installation: https://openwrt.org/docs/guide-user/n...
You can get the Wallys DR4029 router board at: https://www.wallystech.com/products_s...

As mentioned in the video, if you router doesn't have a Mini-PCIe connector for modem, you can purchase a USB to Mini-PCIe with SIM card slot.
There are different modems works well with OpenWRT, for example: Sierra, SIMCom, Quectel; however, please check the supports band of the modem.

Feel free to check out other OpenWRT tutorials on my channel.
If there is anything not clear or there is any question, please leave it in the comment section and we will discuss.
