15MM X 300# Three Pieec Ball Valve With Fire Safe Design Manfacturing Dimension
Автор: AZ Valves Worker
Загружено: 2019-11-01
Просмотров: 289
Описание:
Hello Friends I am valve Worker and today i am going to share something about Valves.
I am going to Share Auto CAD Drawings for Standard & Manufacturing Dimension of a 15MM rating of 300 Class Three Piece Full Bore Ball Valve with Fire Safe Design.
But Before Starting it I want to Introduce my Self I am Mechanical Engineer with Five Plus Years of Experience in the Field of Valve Design & Manufacturing in Company as well as Consulting and Freelancing.
All of These Drawings is not belongs to anyone.
I am Already Manufacturing Valves on these Drawings.
This is only for your Research & Development Purposes.
so don’t wasting Your time lets Begin.
I will Use All Required Standard to make it like.
ASME B 16.5 for Flange Dimension
ASME B 16.10 For Face to Face & End to End Dimension
BS 5 3 5 1 for Manufacturing & Design
ISO 17292 for Wall Thickness or Metal Thickness
And rest all as per Manufacturing Dimension
If anyone want These Originals PDFs Files as well as AutoCAD File
Then Mail me Purchase as per Your Requirements
My Mail Address is [email protected]
