Circuit Assembly Tutorials || How to Build a NOT gate with an NPN Transistor
Автор: philo mech
Загружено: 2014-11-20
Просмотров: 25471
Описание:
Video demonstrates the construction of a NOT gate (inverter) circuit using an NPN transistor.
This is the first installment in a series of videos focused on constructing digital logic gates using standard value NPN transistors. Each video in this series provides a piece of the foundation necessary for a later set of videos that demonstrate the construction of half adder and full adder circuits using NPN transistors.
Parts List:
(1) npn transistor (2n2222, or 2n3904, 2n4401, BC547)
(1) Normally Open momentary button
(2) leds
(3) 1K resistors
(1) 10K resistor
power supply (5, 6, 9V DC)
hookup wire
breadboard
Hope this video was helpful. If so, then please consider clicking like and/or subscribing to my channel. Thank you.
