Cabinet Vision - Swapping hinges via UCS

Описание: In this video I demonstrate how to change hinges with a UCS based on a variety of different conditions for blind panel/extended end cabinets when the doors are set to be a pair.

PDF of the document I referenced during stream can be downloaded here: https://drive.google.com/file/d/1jCAK...

Bi-weekly live streams on Twitch every other Friday at 10:00 AM PDT/PST (GMT-7/GMT-8):   / bward9001

If you appreciate what I'm doing and would like to support future videos, buy me a coffee or simply donate to the cause: https://tinyurl.com/2tnxxrmm

00:00 Introduction
07:55 Use an outline to prepare
20:20 Let's get into it
27:25 Blind Panel Hinge Model
29:45 Filtering for right extended ends
36:00 Changing the right door hinge
40:55 Changing the left door hinge
48:00 Checking off your condititions to address list
50:25 Filtering for left extended ends
52:15 Tidying things up a little
52:55 Formatting your UCS for readability and upkeep
1:02:11 Oops! My exit was not written correctly
1:04:56 Getting rid of the wrong hinge plates
1:07:15 How to climb up THEN down the Object Tree
1:17:20 Adding the right (invisible) hinge plates
1:26:00 Programming joke
1:27:50 Checking my Hardware
