CAN Bus High Resistance Short Circuit | CAN Bus Diagnostics | Mechanic Mindset

Описание: Join Mechanic Mindset and get a FREE multimeter! https://www.mechanicmindset.com/diagn...

Access Free Oscilloscope Diagnostic Training: https://www.mechanicmindset.com/om-fr...

Let's short the network together and see how much resistance this Powertrain CAN Bus network can take?! This test will help you identify CAN Bus Faults to make diagnostics easier. Here I use the PicoScope 2204A to obtain CAN Bus waveform while we dial in a resistive short circuit fault across CAN high and CAN low. The tool is called a decade box and it allows us to select a variety of resistance values. We are performing this test on the high speed powertrain CAN bus network.

Link to PicoScope Waveforms: https://www.mechanicmindset.com/free-...
