Low Pro LIMITED by Felling

Описание: Felling Trailers, Inc. adds the Low Pro Limited to its deck-over tag model line. Known as innovative solution providers to the transportation industry, Felling continually strives to refine their product offerings to be user-focused. "Our engineers improved on our already award-winning design to create a heavy-duty, extremely user-focused construction tag trailer while incorporating all of the standard features an operator wants and needs," said Felling's Sales Manager Nathan Uphus. The Low Pro Limited series currently consists of two models; the FT-45-2 LP Limited, a tandem axle 22-1/2 ton, and the FT-50-3 LP Limited, a triple axle 25 ton. The available deck lengths for the tandem axle are 20’, 22’, & 24’. The available deck lengths for the triple axle are 24’ and 26’.

The Low Pro Limited (LPL) series is constructed with an 8" channel side rail, flange in, with 4" Jr. I-beam crossmembers pierced through the heavy-duty, engineered, and fabricated 16" mainframe with 1-3/8" apitong decking. Apitong decking is an extremely durable wood, making it ideal for construction equipment applications. The LPL's are standard with a 6’ long double incline beavertail providing 12-degree and 6-degree load angles, respectively. The double incline feature eliminates the sharp break-over point, which helps substantially for loading and unloading tracked equipment safely. The 6’ double incline beavertail is constructed with 5” x 3” self-cleaning angles are standard, with apitong inlay offered as a no-cost option. Like the beavertail, the ramps 6’ x 20” wide are available with 5” x 3” self-cleaning angle construction or apitong inlay as a no-cost option.

The hitch area of the LPL’s delivers an increased level of usability to operators. The standard 6’ long hitch includes an oversized toolbox with a few key features: heavy-duty ten gauge cover with a front lip to help keep moisture out, locking t-handle latch, mechanical cover prop a flat bar inside the storage area to hook chains and binders. Keeping operator safety in mind when accessing the deck at the hitch area, the LPL's feature a large, heavy-duty, slip-resistant step. Along with these features, adjustable mounting height brackets for the standard 140K twin 2-seed landing gear have been incorporated into the Limited's hitch design. This allows for the landing gear to be flush with the headboard if necessary.


Low Pro Limited Standard Specifications (tandem & triple axle)
• 16” Fabricated Main Frame Beams
• 4” high tensile Jr I-beams spaced 12” on center
• Standard 1 3/8” thick apitong decking
• Standard 1” Straight D-Rings – 14 on Tandem, 16 on triple Axle
• Heavy-duty, slip-resistant steps with integrated mid-turn LED lights
• 235/75R17.5” Tires and Heavy Duty 3 Leaf spring suspension
• 6’ Double Incline Beavertail – Self Cleaning or Wood Inlaid
• 6’ x 20” Spring Assist Ramps – Self Cleaning or Wood Inlaid
• Optional 38” Wide x 7’ Long Air Powered Ramps (Self Cleaning or Wood Inlaid)
