Flow Through an Orifice (H4) | Fluid Mechanics Experiments with TecQuipment

Описание: Investigate key principles of fluid mechanics with TecQuipment's Flow Through an Orifice Apparatus (H4). This versatile teaching tool allows students to explore the behaviour of water flow through orifices, including:

Coefficient Analysis: Calculate contraction, velocity, and discharge coefficients for a variety of flow rates.
Manometer Integration: Measure total head, head loss, and jet diameter using connected manometer tubes.
Pitot Tube Precision: Adjust the pitot assembly with micrometer-style control for accurate jet head measurements.
Hydraulic Bench Compatibility: Designed for seamless integration with TecQuipment’s Hydraulic Bench (H1F) for flow rate evaluation and recirculating water supply.

Ideal for hands-on experiments, the H4 provides engineering students with critical insights into orifice flow dynamics and fluid behaviour: https://www.tecquipment.com/flow-thro...

#FluidMechanics #OrificeFlow #EngineeringEducation #TecQuipment

00:00 - Introduction to TecQuipment's Flow Through an Orifice Apparatus
00:15 - Key Investigations: Coefficients and Flow Rates
00:30 - Manometers for Measuring Total Head and Head Loss
00:45 - Precision with the Pitot Tube Assembly
01:00 - Recirculating Water with the Hydraulic Bench
01:15 - Direct Measurements of Jet Diameter and Flow Dynamics
01:30 - Advancing Fluid Mechanics Studies with the H4
