Networking Project V3

Описание: My recording stopped working. Here is a list of the steps to follow:
Objective #2
1. Install and Configure the DNS Server
A. Install DNS Server Role
• [ ] Open Server Manager
• [ ] Click Manage → Add Roles and Features
• [ ] Select Role-based or feature-based installation → Next
• [ ] Select DC01 → Next
• [ ] Check DNS Server
• [ ] Accept required features → Next → Install
• [ ] Close the wizard when installation completes
B. Verify DNS Configuration
• [ ] Go to Server Manager → Tools → DNS
• [ ] Expand Forward Lookup Zones
• [ ] Confirm corp.local exists
C. Create a New A Record
• [ ] Right click corp.local → New Host (A or AAAA)
• [ ] Name: www
• [ ] IP Address: 192.168.1.10
• [ ] Click Add Host
D. Create a Reverse Lookup Zone (Recommended)
• [ ] Right click Reverse Lookup Zones → New Zone
• [ ] Choose Primary Zone → Next
• [ ] Select IPv4 Reverse Lookup Zone
• [ ] Network ID: 192.168.1 → Next → Finish
• [ ] Add PTR record for DC01

2. Install and Configure DHCP Server + Create Scopes
A. Install DHCP Server Role
• [ ] Open Server Manager → Add Roles and Features
• [ ] Select DHCP Server → Install
• [ ] After installation, click the notification to Complete DHCP configuration
• [ ] Authorize the DHCP server in Active Directory
B. Create a DHCP Scope
• [ ] Open Server Manager → Tools → DHCP
• [ ] Expand DC01 → IPv4
• [ ] Right click IPv4 → New Scope
• [ ] Configure scope settings:
o [ ] Name: Corp LAN Scope
o [ ] Start IP: 192.168.1.50
o [ ] End IP: 192.168.1.100
o [ ] Subnet mask: 255.255.255.0
o [ ] Router: 192.168.1.1
o [ ] DNS Server: 192.168.1.10
o [ ] DNS Domain: corp.local
• [ ] Activate the scope
C. Test DHCP on CLIENT01
• [ ] Set NIC to Obtain IP automatically
• [ ] Run in CMD:
o [ ] ipconfig /release
o [ ] ipconfig /renew
• [ ] Confirm:
o [ ] IP is in 192.168.1.50–100
o [ ] DNS = 192.168.1.10
o [ ] DHCP Server = 192.168.1.10

3. Install and Configure IIS Web Server
A. Install IIS
• [ ] Open Server Manager → Add Roles and Features
• [ ] Select Web Server (IIS)
• [ ] Accept defaults → Install
B. Verify IIS
• [ ] Open a browser on DC01
• [ ] Go to http://localhost
• [ ] Confirm IIS welcome page loads
C. Customize the Website
• [ ] Navigate to: C:\inetpub\wwwroot
• [ ] Edit iisstart.html or create index.html
D. Test from CLIENT01
• [ ] Open browser
• [ ] Visit:
o [ ] http://192.168.1.10
o [ ] http://www.corp.local

4. Set Up an FTP Server and Test File Transfers
A. Install FTP Components
• [ ] In Add Roles and Features, expand Web Server (IIS)
• [ ] Check:
o [ ] FTP Server
o [ ] FTP Service
o [ ] FTP Extensibility
• [ ] Install
B. Create FTP Root Folder
• [ ] Create folder: C:\FTPShare
• [ ] Set permissions (Domain Users: Read/Write if needed)
C. Create FTP Site
• [ ] Open IIS Manager
• [ ] Right click Sites → Add FTP Site
• [ ] Configure:
o [ ] Name: CorpFTP
o [ ] Path: C:\FTPShare
o [ ] IP: 192.168.1.10
o [ ] Port: 21
o [ ] SSL: No SSL (lab only)
• [ ] Authentication:
o [ ] Basic Authentication
• [ ] Authorization:
o [ ] Allow Specified users or All users
o [ ] Permissions: Read or Read/Write
D. Test FTP from CLIENT01
• [ ] Open File Explorer
• [ ] Enter: ftp://192.168.1.10
• [ ] Log in with a domain user (corp\jdoe)
• [ ] Upload and download a test file
5. Verify Communication Between All Services
A. Test DNS
• [ ] Run on CLIENT01:
o [ ] ping DC01
o [ ] ping corp.local
o [ ] ping www.corp.local
o [ ] nslookup www.corp.local
B. Test DHCP
• [ ] Run ipconfig /all
• [ ] Confirm:
o [ ] DHCP server = 192.168.1.10
o [ ] DNS server = 192.168.1.10
o [ ] IP is from your scope
C. Test IIS
• [ ] Visit:
o [ ] http://192.168.1.10
o [ ] http://www.corp.local
D. Test FTP
• [ ] Connect to ftp://192.168.1.10
• [ ] Upload/download files
