ESP8266 Project | Submersible Pump Control Kit (Part 1)

Описание: Submersible Pump Control Kit (Part 1)

This video demonstrates a low-cost, practical Submersible Pump Control Kit I designed and built from scratch — complete hardware and firmware. The module is intended for homeowners and small-scale users who cannot afford expensive commercial pump controllers but still need a reliable, feature-rich solution.

Overview

In this first part I introduce the Wi-Fi enabled version of the controller and show real-world installation and operation on my home submersible pump. I fully designed the circuit board and wrote the control software myself. I have been running this system in my house for approximately 2.5 months with continuous, trouble-free operation — and I continue to use it daily.

Key Features (current release)

Timer scheduling for automatic pump run cycles

Manual control via a physical switch (local override)

Remote control over Wi-Fi (control the pump from your phone or browser)

Low-voltage and high-voltage protection to safeguard the pump and electronics

Robust relay switching and protection circuitry suitable for domestic submersible pumps

Compact, practical PCB layout optimized for home installations

What’s new in this release

Added Wi-Fi remote-control capability and local physical switch control (this video focuses on those features).

User-friendly operation intended to be simple for non-technical homeowners.

Planned next updates

Integration of a GSM module for SMS-based control and alerts.

Automatic tank overflow shut-off and automatic restart when the tank is empty (level-detection logic).
These enhancements will be covered in subsequent videos/releases — this is Part 1 of the project.

Why this project

My goal was to produce a real-life, practical controller that:

Delivers core protections found in commercial units (voltage protection, reliable switching).

Keeps cost low so more people can adopt safe pump automation.

Field testing & reliability

The system has been deployed and monitored on my home submersible pump for ~2.5 months.

During that time it has provided stable operation and protective behavior against voltage anomalies.

The firmware is designed for dependable operation and safe recovery after power events.

Purchase & direct contact

If you would like to purchase this Submersible Pump Control Kit or contact me directly with questions, please message me on WhatsApp at +91 89679 94554. I handle sales personally and can answer technical questions, provide purchase details, and advise on installation.

Technical & safety notes

This device switches mains voltage. Installation should be performed by a qualified electrician or an experienced technician.

Always follow local electrical codes and safety practices. I demonstrate the hardware and provide guidance, but individual installations are the responsibility of the installer/end user.

Watch, Learn, and Subscribe

If you found this video useful, please like and subscribe to my channel on YouTube for future parts covering GSM integration, tank level automation, and expanded firmware features.

If you need a specific technical detail (schematics, PCB files, firmware, wiring diagrams) mention it in a message on the WhatsApp number above and I will reply with availability and purchase options. Thank you for watching — this is a practical, cost-effective solution built for everyday home use.
