240W GaN Fast Charger: Leadtrend's USB PD 3.2 EPR Reference Design (AHB PFC)
Автор: EEStar
Загружено: 2025-12-08
Просмотров: 29
Описание:
📢 EEStar Reference Design Series: In this episode, we fully test the Leadtrend 240W GaN Fast Charger Reference Design, which supports the cutting-edge USB PD 3.2 EPR standard (5V-48V output).
We break down the technical architecture, including the LD7593DA PFC, the LD7710 AHB (Asymmetric Half-Bridge), and the LD6618CQM PD protocol controller. We also share the comprehensive efficiency and thermal test data collected under 120V and 230V input.
⬇️ Project Resources:
Download the Full DEMO Package (PCB Files, Schematics, BOM, Test Report): [email protected]
Learn More About Leadtrend Solutions: [email protected]
---
⏰ Timecodes / Chapters:
0:00 Introduction & Design Highlights
0:45 PFC Stage (LD7593DA + Renesas GaN)
1:15 AHB Topology (LD7710 + Innoscience GaN)
1:40 Protocol Controller (LD6618CQM PD3.2 EPR)
2:10 Live Testing Setup & Methodology
2:50 Efficiency Test Results (120V & 230V)
4:15 Thermal Performance at Full Load (Key Component Temps)
5:10 Conclusion
Thank you for watching! Subscribe for more deep dives into Power Electronics.
#GaN #USBPD32EPR #240WCharger #PowerElectronics #ReferenceDesign #Leadtrend #AHB #EEStar
